IMPORTANT. This camera uses a Sony Image Sensor component. The quality of image is what you would expect from Sony but without the high price tag for Sony Branded cameras. This is a Masten branded camera.

WIFI Wireless Smart Device Universal Mini Square Premium CCD Camera

The perfect solution for cars and motorcycles

TV FORMAT: PAL

Short description

The WIFI Camera from DIG Options pairs to our Free App for viewing on your device. DIG Options has become the "Installer's Choice" for car audio equipment. We listen to our customers so that they keep listening with us. DIG Options provide the automotive electronics, dash kits, cables, adapters and more so you can keep your vehicle updated with the latest technology.

Cameras from DIG Options are vigorously tested in harsh Australian conditions and backed for an Australia 12 month warranty.

Description

This listing includes 2 parts which are:

  • A Premium Universal CCD Camera
  • WIFI Sender Module and Upgraded Antenna
  • User Manual

About the Camera

  • 150° (vertical viewing angle) High Resolution Mini CCD Reversing Park Camera
  • High Resolution Colour CCD Image Sensor with crisp colour display and the latest sensor technology for improved visibility
  • Best-in-Class PAL 762 (H) 504 (V) Pixel Resolution
  • Impressize 800TVL HD Resolution Image
  • Special trouble-free micro 4-pin connector means you don’t need to drill huge holes and it makes the install easier
  • High Water/Dust Proof Rating
  • Distance guidelines are built into the camera to offer approximate distance grid lines which range from safe to STOP THE CAR!
  • The 170 degree viewing range with advanced CCD Image Sensor provides the latest technology in reverse cameras.
  • Due to the cameras low light properties it works brilliantly at night using the light generated from your reverse lights and the camera is water resistant.
  • Optional Distance Grid Lines
  • High Image Speed of >25 FPS
  • Tested and Certified IP67 Waterproof

Manual

https://www.dropbox.com/s/plxiisph4ai6br8/RC-12%20New%20Manual%20July%202019%20Onwards.pdf?dl=0

Vehicle Compatibility

This part is suitable for all vehicles. Please note that due to this being an aftermarket accessory, some minor work may be required however, you will end up with a good result.

Camera Specifications
Image Sensor CCD (Sony)
TV System PAL
Pixels 762 (H) x 504 (V)
Resolution 800TVL
Lumination 0.1LUX
Viewing Angle 170deg
Video Out 1.0VPP at 75R
Power Supply 3.3V
Water/Dust Proof IP67
Wireless Specifications
Support 802.11g/n, 802.11b
Interface Type RCA Composite
Power 2.5W
Pixel 30W
Transmission Mode AP
Transmission Speed Max. 128mHZ
Antenna External - Masten Brand
Sensitivity <-65dbm
RF 2412-2482
LED On
Transmission Distance Max. 40M (Clear View)
Compatible OS Android/iOS
Power Supply 12V
SKU RC-12
Barcode # 729436060760
Brand Masten
Shipping Weight 0.2500kg
Shipping Width 0.130m
Shipping Height 0.070m
Shipping Length 0.035m
Assembled Width 0.130m

1 Year Warranty
